Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness

Wuxi Orient Anti-wear Engineering Co.,Ltd.
Contact Now

Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness

  • 1
  • 2

Place of Origin : Jiangsu, China (Mainland)

Brand Name : Chen's Liner

Model Number : DF041

MOQ : 2 Ton/Tons

Price : Discuss in email

Packaging Details : Packed by steel pallets.

Delivery Time : It depends on the quantity to be ordered.

Payment Terms : L/C,T/T

Supply Ability : 4500 Ton/Tons per Year

Port : Shanghai

Certification : ISO 9001

Application : Mine mill

Material : Steel

Dimensions : As per drawings

Hardness : Less than HB300

Impact Value : More than AK147J

Product Name : Mn Steel Casting

Contact Now

Mn18Cr2 Wear-resistant Castings Hammers Less than HB300 Hardness



Specification

1. Material:High Mn Steel

2. Hardness:Less Than HB300

3. Application:Mining Industry

4. MOQ:2tons



Product Photo

Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness  Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness



Technical Parameters

Item High Cr White Iron High Cr Alloy Steel High Mn Steel Ni-hard Cast Iron
C 2.4-3.2 1.1-2.2 0.9-1.3 2.4-3.6
Si 0.6-1.2 0.6-1.2 ≤0.8 ≤0.8
Mn 0.5-1.0 0.5-1.0 11.0-18.0 ≤2.0
Cr 12.0-30.0 11.0-30.0 1.5-2.5 1.5-10
S ≤0.04 ≤0.04 ≤0.04 ≤0.15
P ≤0.06 ≤0.06 ≤0.06 ≤0.15
Mo 0.1-3.0 0.1-3.0 ≤1.0 ≤0.1
Cu 0.1-1.0 0.1-1.0 - -
Ni 0-0.3 0-0.3 - 3.3-10
Re - - - -
Equivalent
Specification
GB/T8263-1999
AS2027 Cr27
AS2027 CrMo 15/3
AS2027 CrMo 20/2/1
ASTM A532 Class Ⅲ Type A 25%Cr
ASTM A532 Class Ⅱ Type B 15%Cr-Mo
BS 4844 3E
DIN1695
NFA32401
GB/T5680-1998
DL/T 681-1999
JIS G 5153-1999
ASTM A128
DIN GX120Mn12
AFNORZ120Mn12
GB/T8263-1999
AS2027/Ni-Cr1-550
AS2027/Ni-Cr2-500
AS2027/Ni-Cr4-500
AS2027/Ni-Cr4-600
AS2027/Ni-Cr4-630
ASTM A532 1-A,B,C,D
ASTM A532 2-A,B,C,D,E
ASTM A532 3-A
Material Type Martensite Matrix Austenitic Mn Steel -
Hardness HRC≥56 HB≤300 HRC≥56
Impact Value AK≥4J AK≥80J -



Production Facilities

                             1T,1.5T,3T,5T,12T,15T

       Induction Electrical Furnace                          Heat Treatment Electrical Furnace

      Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness         Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness

Inspection Facilities

Spectrometer                                                   Portable Hardness Tester

       Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness         Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness



                                             UT Test                                       Electronic Metallographic Microscope

                 Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness          Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness



Process



Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness















































































Honor

Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness   Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness    Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness



About Us

We are a Chinese specialized manufacturer of wear, heat and corrosion-resistant castings.

Our main products are ball mill liners, grinding media and wear parts for crushers.



The area for our foundry is about 30,000 square meters. The capacity of our company is 30,000MT/year

and the single piece is from 15kg to 20tons. The capacitiesof Mid-frequency induction electric furnaces

are 15tons,12tons, 5tons,2tons,1.5tons and 1.2tons. And we have 10 sets of heat-treatment electrical  furnaces with capacity of 30 tons, 10 tons,3 tons.

Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness  Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness   Mn18Cr2 Wear-resistant Castings Hammers Conform To GB/T 5680-1998 Less than HB300 Hardness



Our Services

We supply the following services:
1. Production of qualified wear and heat castings;
2. Design and installation of the boltless mill liners;
3. Consulting service of material selection of the mill liners under specific working condition to achieve

 longer service life;
4. Consulting service of production & fineness improvement of grinding mills.
5.We can provide OEM/ODM for our clients.
